A RUIYANG HDPE crane mat measures 1220 × 2440 mm (4 × 8 ft) and weighs 29.7 kg at 10 mm and 268.1 kg at 70–90 mm — about 2.98 kg per millimetre of thickness. Across the full 10–90 mm range the same footprint increases in weight 9× while its third-party verified load rating climbs from 25 T to 280 T. The crane mat weight calculator below returns both numbers for your equipment in one step.

Crane mat weight is a procurement question with three parts: what a single mat weighs, how many you can legally put on a truck, and how heavy a panel your crew can still position by hand. Get those three numbers right and you avoid the two most common ordering mistakes — buying thickness your install method cannot handle, and paying freight twice because the first load was under-planned.

HDPE crane mat weight chart (1220 × 2440 mm)

The table below is the complete weight and load-rating matrix for RUIYANG HDPE crane mats. Weight scales linearly with thickness, so the ratio in the last column is constant at roughly 2.98 kg per millimetre.

Thickness	Weight per mat	Weight per m²	Weight per mat (lb)	Load rating
10 mm	29.7 kg	10.0 kg	65 lb	25–33 T
15 mm	44.6 kg	15.0 kg	98 lb	38–47 T
20 mm	59.5 kg	20.0 kg	131 lb	52–64 T
25 mm	74.4 kg	25.0 kg	164 lb	65–78 T
30 mm	89.3 kg	30.0 kg	197 lb	80–95 T
35 mm	104.2 kg	35.0 kg	230 lb	92–110 T
40 mm	119.1 kg	40.0 kg	263 lb	105–125 T
50 mm	148.9 kg	50.0 kg	328 lb	130–155 T
60 mm	178.7 kg	60.0 kg	394 lb	160–185 T
70–90 mm	268.1 kg	90.1 kg	591 lb	190–280 T

Every figure above is a RUIYANG factory specification for a 1220 × 2440 mm mat with dual-side anti-slip texture, interlocking connectors, 0% water absorption and a 20+ year reusable life. Load ratings are third-party verified for the full 25–280 T range.

The crane mat weight formula

You do not need a calculator for a single panel, only for a fleet:

Same footprint (4 × 8 ft): weight in kg = thickness in mm × 2.98. A 35 mm mat is 35 × 2.98 ≈ 104.2 kg.
Any footprint: weight in kg = area in m² × thickness in mm × 1.0 — HDPE mats work out at almost exactly 1 kg per m² per millimetre of thickness.
A whole fleet: total weight = number of mats × unit weight. A 30 × 4 m access route needs 52 mats, which is 1,544 kg at 10 mm or 7,743 kg at 50 mm.

If you want the fleet number without doing the arithmetic, the thickness calculator outputs the recommended thickness, the mat count, the total weight and the container count together.

Load a crane scenario into the calculator

Each button opens the calculator with the equipment weight, ground condition and route size already filled in. Change anything once you are there.

25 t mobile crane Firm ground · 20 × 3 m route Open in calculator → 60 t crane on sand Sand · 25 × 4 m route Open in calculator → 130 t crawler crane Firm ground · 60 × 8 m platform Open in calculator →

How many crane mats fit on a truck?

Transport is limited by legal payload, not by deck area. Against a working payload of 24 t the weight ceiling looks like this:

Thickness	Unit weight	Mats within a 24 t payload
10 mm	29.7 kg	808
15 mm	44.6 kg	538
20 mm	59.5 kg	403
25 mm	74.4 kg	322
30 mm	89.3 kg	268
35 mm	104.2 kg	230
40 mm	119.1 kg	201
50 mm	148.9 kg	161
60 mm	178.7 kg	134
70–90 mm	268.1 kg	89

Treat these as ceilings, not plans. On a 12.2 m flatbed, a 2.44 m long mat gives 10 mats per layer, so 808 panels would be an 81-layer stack — physically impossible. In practice the deck length and stack height bind first at thin gauges, and the weight limit only becomes the controlling constraint from about 30 mm upward. Always confirm axle and route permits with your haulier before quoting a load.

Ocean freight behaves the same way. RUIYANG loads HDPE mats into a 40HQ container on a 26 t payload basis: 875 mats at 10 mm, 582 at 15 mm, 436 at 20 mm, 349 at 25 mm, 291 at 30 mm, 249 at 35 mm, 218 at 40 mm, 174 at 50 mm, 145 at 60 mm and 96 at 70–90 mm. Notice how fast the count collapses: the same container that carries 875 thin mats carries 96 deep ones, which is why thickness is a freight decision as much as an engineering one.

Weight vs handling: what your crew can actually install

Panel weight decides the install method, and the install method decides your labour cost. As a practical rule:

Up to 15 mm (29.7 kg / 44.6 kg) — two workers position and lock panels by hand. This is the range that makes a crane-free temporary road genuinely crane-free.
20–25 mm (59.5 kg / 74.4 kg) — two workers can still manage short moves, but most sites want a panel trolley or a telehandler for a full-day lay.
30–40 mm (89.3 kg / 119.1 kg) — mechanical handling. Small excavator, skid-steer or forklift.
50 mm and above (148.9 kg / 268.1 kg) — crane or excavator lift, and usually a permanent or semi-permanent crane pad rather than a relocatable road.

Buyers moving from steel or timber notice this most. A 20 mm steel road plate of the same 4 × 8 ft footprint weighs about 467 kg and needs a crane on every move; a 20 mm HDPE mat weighs 59.5 kg with a comparable 52–64 T rating. A 25 mm steel plate is roughly 584 kg. Typical 100–200 mm timber crane mats land somewhere between 150 kg and 350 kg per panel — and unlike HDPE they gain weight in the rain, because timber absorbs water while HDPE absorbs 0%.

Weight is not a proxy for strength

The reflex is to assume heavier means stronger. In ground protection it is the opposite: HDPE mats deliver their rating through a solid, sealed core and a large contact area rather than through mass. That is why the same 4 × 8 ft footprint scales from 29.7 kg to 268.1 kg and from 25 T to 280 T with nothing but thickness — a 9× weight change for an 11× load change, with no reinforcement or coatings to drive cost, freight or moisture problems.

If you are weighing HDPE against timber on a like-for-like basis, see composite vs timber mats. For matching a thickness to a machine, the crane mats guide and the specifications hub cover the full matrix.

Frequently Asked Questions

How much does a crane mat weigh?

A RUIYANG HDPE crane mat measuring 1220 × 2440 mm (4 × 8 ft) weighs 29.7 kg at 10 mm, 59.5 kg at 20 mm, 119.1 kg at 40 mm and 268.1 kg at 70–90 mm. Across the full range that is about 2.98 kg per millimetre of thickness for this footprint.

How do I calculate crane mat weight?

For a 1220 × 2440 mm HDPE mat, multiply the thickness in millimetres by 2.98 kg. A 25 mm panel is therefore about 74.4 kg. For any other footprint, use the area rule: a 1 mm thick HDPE panel weighs about 1 kg per square metre.

Are HDPE crane mats lighter than timber crane mats?

Yes, per panel and per load rating. A typical 100–200 mm timber crane mat of the same 4 × 8 ft footprint weighs roughly 150–350 kg, while a 20 mm HDPE mat rated 52–64 T weighs 59.5 kg. HDPE mats also absorb no water, so their weight does not change when the site turns wet.

How many crane mats fit on a flatbed truck?

It depends on your legal payload, not the deck area. Against a 24 t payload, weight alone permits about 808 mats at 10 mm, 403 at 20 mm, 201 at 40 mm or 89 at 70–90 mm. In practice stack height and deck length limit the load long before the weight ceiling at thin thicknesses.

How many 20 mm HDPE mats fit in a 40HQ container?

436 mats of 1220 × 2440 × 20 mm. HDPE mats load out weight-limited, not volume-limited: a 40HQ holds about 26 t of payload, and 436 × 59.5 kg is roughly 26 t. For the same container check 875 mats at 10 mm, 291 at 30 mm or 96 at 70–90 mm.

Can two workers lift an HDPE crane mat by hand?

Up to 15 mm yes — 29.7 kg and 44.6 kg per panel are normal two-person loads. From 20 mm upward (59.5 kg and above) most sites require mechanical handling or a panel trolley, and 50 mm and above (148.9 kg) needs a machine.

Do crane mats get heavier when wet?

HDPE mats do not: they have 0% water absorption, so a wet panel weighs exactly the same as a dry one. Timber mats do gain weight because they soak up water, which is why timber mat weights are usually quoted as air-dry figures that cannot be relied on after rain.
